• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High strength composite with reinforced stainless steel bolt ferrules for high load capacity and increased strength around the bolt holes.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Thread Size	1/2-13
Overall Length (in)	4.63 in
Base Width (in)	1.88 in
Overall Height (in)	3.93 in
Overall Width (in)	1.94 in
Bore Diameter (in)	1.5000 in
Thread Depth (in)	0.75 in
Base to Center Height (in)	1.9375 in
Length Through Bore (in)	1.9375 in
Bolt Spacing (in)	3.500 in
Centerline to Outermost Bearing Face (in)	1.1875 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Housing Construction	One Piece
Bore Shape	Straight
Housing Color	Gray
Options	Corrosion Resistant
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Pillow Block, Tapped Base
Housing Style	Pillow Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Radial Clearance	Standard
Dynamic Load Rating (lb)	7,340 lb
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Static Load Rating (lb)	4,467 lb
End Cap Available	Yes
Bearing Insert Finish	Phosphorus Nickel Coated
Housing Material	Composite
Grease Fitting Thread Size	1/4-28
Cage Type	Land Riding Retainer
Max Operating Temperature (F)	220 °F
Bearing Type	Standard Duty
Base Length (in)	4.625 in
Size Code	2-19
Insert	PN-24
Bearing Insert Material	52100 Bearing Steel
Misalignment Capability	±2.0° Misalignment - Static Only
Shaft Locking Type	Set Screw
Maximum Speed (RPM)	1750 rpm
Inner Ring Outside Diameter (in)	2.0625 in
Fixed vs. Expansion	Fixed
Housing Width (in)	1.88 in

General Specifications

UPC	662461335727
Weight	2.77 LB
Packaged Length	5.50 IN
Packaged Width	2.13 IN
Packaged Height	5.50 IN
HTC	8483.20.8040
Country of Origin	United States of America
