• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High strength composite with reinforced stainless steel bolt ferrules for high load capacity and increased strength around the bolt holes.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Thread Size	7/16-14
Base Width (in)	1.50 in
Overall Length (in)	4 in
Overall Height (in)	3.38 in
Overall Width (in)	1.5 in
Bore Diameter (in)	1.1875 in
Base to Center Height (in)	1.688 in
Thread Depth (in)	0.63 in
Length Through Bore (in)	1.50 in
Centerline to Outermost Bearing Face (in)	0.88 in
Bolt Spacing (in)	3.00 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Bore Shape	Straight
Housing Construction	One Piece
Options	Corrosion Resistant
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Color	Gray
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Pillow Block, Tapped Base
Seal Type	Multi-Lip Contact Seal
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Setscrew Torque (in-lbs)	65-85 in/lbs
Ability to Relubricate	Yes
Misalignment Capability	±2.0° Misalignment - Static Only
Vibration Frequency Inner Ring Defect	0.0905 cps
Insert	PN-19
Bearing Type	Standard Duty
Grease Fitting Thread Size	1/4-28
Dynamic Load Rating (lb)	4,381 lb
Maximum Speed (RPM)	2300 rpm
Bearing Insert Finish	Phosphorus Nickel Coated
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
End Cap Available	Yes
Shaft Locking Type	Set Screw
Vibration Frequency Fundamental Train	0.0066 cps
Static Load Rating (lb)	2,567 lb
Size Code	2-13
Vibration Frequency Outer Ring Defect	0.0595 cps
Radial Clearance	Standard
Vibration Frequency Roller Spin	0.0385 cps
Inner Ring Outside Diameter (in)	1.594 in
Cage Type	Land Riding Retainer
Housing Material	Composite
Max Operating Temperature (F)	220 °F
Fixed vs. Expansion	Fixed
Base Length (in)	4.00 in
Bearing Insert Material	52100 Bearing Steel
Housing Width (in)	1.5 in

General Specifications

UPC	662461339398
Weight	1.57 LB
Packaged Length	4.50 IN
Packaged Width	1.69 IN
Packaged Height	4.56 IN
HTC	8483.20.8040
Country of Origin	United States of America
