• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High strength composite with reinforced stainless steel bolt ferrules for high load capacity and increased strength around the bolt holes.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Thread Size	3/8-16
Base Width (in)	1.50 in
Overall Length (in)	3 in
Overall Height (in)	2.81 in
Overall Width (in)	1.5 in
Bore Diameter (in)	1 in
Thread Depth (in)	0.5 in
Base to Center Height (in)	1.438 in
Length Through Bore (in)	1.375 in
Centerline to Outermost Bearing Face (in)	0.81 in
Bolt Spacing (in)	2.00 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Options	Corrosion Resistant
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Gray
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Pillow Block, Tapped Base
Housing Style	Pillow Block
Setscrew Torque (in-lbs)	65-85 in/lbs
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Vibration Frequency Inner Ring Defect	0.0985 cps
Maximum Speed (RPM)	2700 rpm
Misalignment Capability	±2.0° Misalignment - Static Only
Base Length (in)	3.00 in
End Cap Available	Yes
Bearing Type	Standard Duty
Size Code	2-015
Shaft Locking Type	Set Screw
Insert	PN-16
Dynamic Load Rating (lb)	2,801 lb
Inner Ring Outside Diameter (in)	1.38 in
Static Load Rating (lb)	1,651 lb
Vibration Frequency Fundamental Train	0.0068 cps
Fixed vs. Expansion	Fixed
Vibration Frequency Roller Spin	0.0442 cps
Cage Type	Land Riding Retainer
Bearing Insert Finish	Phosphorus Nickel Coated
Max Operating Temperature (F)	220 °F
Grease Fitting Thread Size	1/4-28
Radial Clearance	Standard
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Vibration Frequency Outer Ring Defect	0.0682 cps
Bearing Insert Material	52100 Bearing Steel
Housing Material	Composite
Housing Width (in)	1.5 in

General Specifications

UPC	662461335710
Weight	0.93 LB
Packaged Length	4.00 IN
Packaged Width	1.50 IN
Packaged Height	3.94 IN
HTC	8483.20.8040
Country of Origin	United States of America
