• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• Fluoropolymer coated cast iron housing for corrosion resistance.
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Height (in)	5.75 in
Overall Width (in)	2.25 in
Overall Length (in)	6.75 in
Bore Diameter (in)	2 in
Base to Center Height (in)	4.19 in
Length Through Bore (in)	2.185 in
Slot Width (in)	1.063 in
Slot Spacing (in)	5.125 in
Centerline to Outermost Bearing Face (in)	1.313 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Construction	One Piece
Bore Shape	Straight
Options	Corrosion Resistant
Misalignment Type	Static Only
Housing Color	Gray
Outer Ring Land Profile	Standard
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Series	CRSTF
Seal Type	Multi-Lip Contact Seal
Housing Type	Take-Up Block, Wide Slot
Slot Length (in)	3.75 in
Housing Style	Take-Up Block
Adjusting Screw Clearance Hole Diameter (in)	1.38 in
Carriage Bolt Size (in)	1 in
Inner Race Heat Treat Method	Zone-Hardened
Adjusting Screw Square Nut Seat Height (in)	2.5 in
Ability to Relubricate	Yes
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Shaft Locking Type	Set Screw
Cage Type	Land Riding Retainer
Radial Clearance	Standard
Grease Fitting Thread Size	1/8 NPT
Misalignment Capability	±2.0° Misalignment - Static Only
Vibration Frequency Outer Ring Defect	0.0680 cps
Maximum Speed (RPM)	1350 rpm
Bearing Type	Standard Duty
Vibration Frequency Inner Ring Defect	0.0987 cps
Size Code	2-23
Bearing Insert Material	52100 Bearing Steel
Static Load Rating (lb)	6,601 lb
Inner Ring Outside Diameter (in)	2.719 in
End Cap Available	Yes
Dynamic Load Rating (lb)	9,752 lb
Max Operating Temperature (F)	220 °F
Insert	PN-32
Fixed vs. Expansion	Fixed
Vibration Frequency Roller Spin	0.0437 cps
Housing Material	Cast Iron
Vibration Frequency Fundamental Train	0.0068 cps
Bearing Insert Finish	Phosphorus Nickel Coated
Housing Coating	Flouropolymer Coated

General Specifications

UPC	662461339367
Weight	9.80 LB
Packaged Length	7.19 IN
Packaged Width	7.00 IN
Packaged Height	3.31 IN
HTC	8483.20.4040
Country of Origin	United States of America
