• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• Fluoropolymer coated cast iron housing for corrosion resistance.
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Height (in)	4.00 in
Overall Width (in)	1.75 in
Overall Length (in)	5.06 in
Bore Diameter (in)	1.4375 in
Base to Center Height (in)	3.06 in
Length Through Bore (in)	1.685 in
Slot Width (in)	0.531 in
Slot Spacing (in)	3.500 in
Centerline to Outermost Bearing Face (in)	1.00 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Gray
Options	Corrosion Resistant
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Certifications	IP69K
Series	CRSTF
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Take-Up Block, Wide Slot
Seal Type	Multi-Lip Contact Seal
Slot Length (in)	2.50 in
Housing Style	Take-Up Block
Carriage Bolt Size (in)	5/8 in
Adjusting Screw Square Nut Seat Height (in)	1.44 in
Adjusting Screw Clearance Hole Diameter (in)	0.88 in
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Bearing Type	Standard Duty
Grease Fitting Thread Size	1/4-28
Housing Coating	Flouropolymer Coated
Insert	PN-23
Max Operating Temperature (F)	220 °F
Size Code	2-17
Misalignment Capability	±2.0° Misalignment - Static Only
Fixed vs. Expansion	Fixed
Vibration Frequency Inner Ring Defect	0.0905 cps
Vibration Frequency Fundamental Train	0.0066 cps
Radial Clearance	Standard
Static Load Rating (lb)	3,493 lb
Inner Ring Outside Diameter (in)	1.859 in
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
End Cap Available	Yes
Housing Material	Cast Iron
Dynamic Load Rating (lb)	5,782 lb
Maximum Speed (RPM)	2000 rpm
Vibration Frequency Roller Spin	0.0386 cps
Shaft Locking Type	Set Screw
Cage Type	Land Riding Retainer
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Outer Ring Defect	0.0595 cps
Bearing Insert Finish	Phosphorus Nickel Coated

General Specifications

UPC	662461337264
Weight	4.00 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.4040
Country of Origin	United States of America
