• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• Fluoropolymer coated cast iron housing for corrosion resistance.
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Height (in)	4.63 in
Overall Width (in)	2.19 in
Overall Length (in)	5.69 in
Bore Diameter (mm)	45 mm
Length Through Bore (in)	1.934 in
Slot Width (in)	0.688 in
Slot Spacing (in)	4 in
Centerline to Outermost Bearing Face (in)	1.19 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Gray
Outer Ring Land Profile	Tapered Lands
Options	Corrosion Resistant - Reduced Maintenance - Lubed for Life
Misalignment Type	Static Only
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Take-Up Block, Wide Slot
Slot Length (in)	3.25 in
Housing Style	Take-Up Block
Inner Race Heat Treat Method	Zone-Hardened
Adjusting Screw Clearance Hole Diameter (in)	1.13 in
Adjusting Screw Square Nut Seat Height (in)	1.94 in
Carriage Bolt Size (in)	3/4 in
Ability to Relubricate	No
Insert	PN-209
Housing Coating	Flouropolymer Coated
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Size Code	2-111
Dynamic Load Rating (lb)	7,901 lb
Static Load Rating (lb)	5,139 lb
Bearing Insert Finish	Phosphorus Nickel Coated
Fixed vs. Expansion	Fixed
Cage Type	Land Riding Retainer
Bearing Insert Material	52100 Bearing Steel
Misalignment Capability	±2.0° Misalignment - Static Only
Maximum Speed (RPM)	1600 rpm
Vibration Frequency Fundamental Train	0.0067 cps
End Cap Available	No
Vibration Frequency Outer Ring Defect	0.0673 cps
Bearing Type	Standard Duty
Vibration Frequency Inner Ring Defect	0.0994 cps
Shaft Locking Type	Set Screw
Grease Fitting Thread Size	1/4-28
Housing Material	Cast Iron
Radial Clearance	Standard
Inner Ring Outside Diameter (in)	2.307 in
Vibration Frequency Roller Spin	0.0417 cps
Max Operating Temperature (F)	220 °F

General Specifications

UPC	662461392188
Weight	5.80 LB
Packaged Length	4.63 IN
Packaged Width	2.31 IN
Packaged Height	7.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
