• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• Fluoropolymer coated cast iron housing for corrosion resistance.
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Length (in)	4.44 in
Overall Width (in)	1.75 in
Overall Height (in)	4.00 in
Bore Diameter (in)	1.1875 in
Base to Center Height (in)	2.75 in
Length Through Bore (in)	1.50 in
Slot Width (in)	0.531 in
Slot Spacing (in)	3.500 in
Centerline to Outermost Bearing Face (in)	0.875 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Construction	One Piece
Bore Shape	Straight
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Color	Gray
Options	Corrosion Resistant
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Series	CRSTF
Housing Type	Take-Up Block, Wide Slot
Seal Type	Multi-Lip Contact Seal
Slot Length (in)	2.25 in
Housing Style	Take-Up Block
Inner Race Heat Treat Method	Zone-Hardened
Adjusting Screw Square Nut Seat Height (in)	1.44 in
Setscrew Torque (in-lbs)	65-85 in/lbs
Ability to Relubricate	Yes
Carriage Bolt Size (in)	5/8 in
Adjusting Screw Clearance Hole Diameter (in)	0.88 in
Housing Material	Cast Iron
Fixed vs. Expansion	Fixed
Misalignment Capability	±2.0° Misalignment - Static Only
Maximum Speed (RPM)	2300 rpm
Static Load Rating (lb)	2,567 lb
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Insert	PN-19
Housing Coating	Flouropolymer Coated
Cage Type	Land Riding Retainer
Vibration Frequency Roller Spin	0.0385 cps
Grease Fitting Thread Size	1/4-28
Vibration Frequency Inner Ring Defect	0.0905 cps
Radial Clearance	Standard
Max Operating Temperature (F)	220 °F
Inner Ring Outside Diameter (in)	1.594 in
Vibration Frequency Outer Ring Defect	0.0595 cps
Size Code	2-13
Shaft Locking Type	Set Screw
Bearing Insert Finish	Phosphorus Nickel Coated
Bearing Insert Material	52100 Bearing Steel
Dynamic Load Rating (lb)	4,381 lb
End Cap Available	Yes
Vibration Frequency Fundamental Train	0.0066 cps
Bearing Type	Standard Duty

General Specifications

UPC	662461339299
Weight	3.40 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.4040
Country of Origin	United States of America
