• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• Fluoropolymer coated cast iron housing for corrosion resistance.
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	1.38 in
Overall Height (in)	3.50 in
Overall Length (in)	3.81 in
Bore Diameter (in)	1 in
Base to Center Height (in)	2.44 in
Length Through Bore (in)	1.375 in
Slot Width (in)	0.531 in
Slot Spacing (in)	3.000 in
Centerline to Outermost Bearing Face (in)	0.813 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Options	Corrosion Resistant
Housing Color	Gray
Misalignment Type	Static Only
Certifications	IP69K
Series	CRSTF
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Take-Up Block, Wide Slot
Slot Length (in)	2.00 in
Housing Style	Take-Up Block
Adjusting Screw Square Nut Seat Height (in)	1.25 in
Inner Race Heat Treat Method	Zone-Hardened
Carriage Bolt Size (in)	5/8 in
Ability to Relubricate	Yes
Adjusting Screw Clearance Hole Diameter (in)	0.75 in
Setscrew Torque (in-lbs)	65-85 in/lbs
Shaft Locking Type	Set Screw
End Cap Available	Yes
Static Load Rating (lb)	1,651 lb
Bearing Insert Finish	Phosphorus Nickel Coated
Bearing Insert Material	52100 Bearing Steel
Cage Type	Land Riding Retainer
Maximum Speed (RPM)	2700 rpm
Dynamic Load Rating (lb)	2,801 lb
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Fixed vs. Expansion	Fixed
Vibration Frequency Roller Spin	0.0442 cps
Size Code	2-015
Bearing Type	Standard Duty
Housing Material	Cast Iron
Housing Coating	Flouropolymer Coated
Radial Clearance	Standard
Inner Ring Outside Diameter (in)	1.375 in
Vibration Frequency Fundamental Train	0.0068 cps
Misalignment Capability	±2.0° Misalignment - Static Only
Vibration Frequency Outer Ring Defect	0.0682 cps
Insert	PN-16
Vibration Frequency Inner Ring Defect	0.0985 cps
Max Operating Temperature (F)	220 °F
Grease Fitting Thread Size	1/4-28

General Specifications

UPC	662461337745
Weight	1.97 LB
Packaged Length	4.50 IN
Packaged Width	1.69 IN
Packaged Height	4.56 IN
HTC	8483.20.4040
Country of Origin	United States of America
