Dimensions

Overall Height (in)	3.75 in
Bolt Size (in)	1/2 in
Foot Height (in)	0.63 in
Length Through Bore (in)	1.685 in
Bore Diameter (in)	1.25 in
Overall Width (in)	1.88 in
Base Width (in)	1.88 in
Base to Center Height (in)	1.875 in
Overall Length (in)	10.25 in
Bolt Spacing (in)	5 in
Bolt Spacing Max (in)	5.31 in
Bolt Spacing Min (in)	4.69 in
Centerline to Outermost Bearing Face (in)	1 in

Technical Specifications

Bore Shape	Straight
Housing Base	Solid
Housing Style	Pillow Block
Misalignment Type	Static Only
Rolling Element	Ball Bearing
Housing Type	Pillow Block, Two Bolt
Cage Material	PPS - Polyphenylene Sulfide
Certifications	IP69K
Ability to Relubricate	No
Housing Color	Silver
Housing Construction	One Piece
Max Operating Temperature (F)	220 °F
Vibration Frequency Roller Spin	0.0386 cps
Radial Clearance	Standard
Maximum Speed (RPM)	2000 rpm
Base Length (in)	6.56 in
Housing Material	Stainless Steel
Size Code	2-17
End Cap Available	Yes
Cage Type	Land Riding Retainer
Fixed vs. Expansion	Fixed
Vibration Frequency Inner Ring Defect	0.0905 cps
Vibration Frequency Fundamental Train	0.0066 cps
Bearing Type	Standard Duty
Shaft Locking Type	Set Screw
Static Load Rating (lb)	4,915 lb
Bearing Insert Material	440C Stainless Steel
Misalignment Capability	±2.0° Misalignment - Static Only
Grease Fitting Thread Size	1/4-28
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Inner Ring Outside Diameter (in)	1.851 in
Vibration Frequency Outer Ring Defect	0.0595 cps
Dynamic Load Rating (lb)	4,915 lb

General Specifications

UPC	662461422588
Weight	4.50 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.8040
Country of Origin	United States of America
