• 440C Stainless steel for corrosion resistance.
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• USDA H1 complaint food grade grease

Dimensions

Overall Length (in)	10.25 in
Bolt Size (in)	1/2 in
Base to Center Height (in)	1.6875 in
Base Width (in)	1.88 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.497 in
Bore Diameter (in)	1.1875 in
Overall Width (in)	1.88 in
Overall Height (in)	3.38 in
Bolt Spacing (in)	4.75 in
Centerline to Outermost Bearing Face (in)	0.875 in
Bolt Spacing Min (in)	4.44 in
Bolt Spacing Max (in)	5.06 in

Technical Specifications

Bore Shape	Straight
Housing Type	Pillow Block, Two Bolt
Seal Type	Triple Lip Contact Seal
Housing Construction	One Piece
Certifications	IP69K
Housing Base	Solid
Options	Corrosion Resistant
Rolling Element	Ball Bearing
Outer Ring Land Profile	Standard
Housing Color	Silver
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Style	Pillow Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Through Hardened with annealed set screw hole
Base Length (in)	6.5 in
Max Operating Temperature (F)	220 °F
Grease Fitting Thread Size	1/4-28
Vibration Frequency Fundamental Train	0.0066 cps
Misalignment Capability	±2.0° Misalignment - Static Only
Vibration Frequency Outer Ring Defect	0.0595 cps
Shaft Locking Type	Set Screw
Radial Clearance	Standard
Dynamic Load Rating (lb)	3,724 lb
Vibration Frequency Inner Ring Defect	0.0905 cps
Maximum Speed (RPM)	2300 rpm
End Cap Available	Yes
Housing Material	Stainless Steel
Inner Ring Outside Diameter (in)	1.594 in
Cage Type	Land Riding Retainer
Bearing Insert Material	440C Stainless Steel
Static Load Rating (lb)	2,182 lb
Bearing Type	Standard Duty
Size Code	2-13
Vibration Frequency Roller Spin	0.0385 cps
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Insert	SS-19
Fixed vs. Expansion	Fixed

General Specifications

UPC	662461421505
Weight	1.90 LB
Packaged Length	3.19 IN
Packaged Width	1.69 IN
Packaged Height	5.25 IN
HTC	8483.20.8040
Country of Origin	United States of America
