• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Length (in)	8.63 in
Overall Height (in)	5.00 in
Overall Width (in)	2.38 in
Base Width (in)	2.38 in
Bolt Size (in)	5/8 in
Bore Diameter (in)	2.1875 in
Foot Height (in)	0.75 in
Base to Center Height (in)	2.5000 in
Length Through Bore (in)	2.188 in
Bolt Spacing Min (in)	6.5 in
Bolt Spacing Max (in)	7 in
Centerline to Outermost Bearing Face (in)	1.313 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Options	Corrosion Resistant - Reduced Maintenance - Lubed for Life
Housing Color	Silver
Outer Ring Land Profile	Tapered Lands
Misalignment Type	Static Only
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	No
Size Code	2-23
Cage Type	Land Riding Retainer
Max Operating Temperature (F)	220 °F
Base Length (in)	8.63 in
Shaft Locking Type	Set Screw
Vibration Frequency Roller Spin	0.0437 cps
Bearing Insert Finish	Phosphorus Nickel Coated
Insert	PN-35
Maximum Speed (RPM)	1350 rpm
End Cap Available	Yes
Vibration Frequency Fundamental Train	0.0068 cps
Bearing Insert Material	52100 Bearing Steel
Dynamic Load Rating (lb)	9,752 lb
Static Load Rating (lb)	6,601 lb
Bearing Type	Standard Duty
Inner Ring Outside Diameter (in)	2.719 in
Grease Fitting Thread Size	1/8 NPT
Fixed vs. Expansion	Fixed
Housing Material	Stainless Steel
Vibration Frequency Inner Ring Defect	0.0987 cps
Misalignment Capability	±2.0° Misalignment - Static Only
Radial Clearance	Standard
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Vibration Frequency Outer Ring Defect	0.068 cps

General Specifications

UPC	662461339237
Weight	9.70 LB
Packaged Length	8.88 IN
Packaged Width	5.94 IN
Packaged Height	2.63 IN
HTC	8483.20.8040
Country of Origin	United States of America
