• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Skwezloc® Concentric locking for near perfect concentricity with fluoropolymer coated collar and corrosion resistant cap screw
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	2.13 in
Overall Length (in)	7.5 in
Overall Height (in)	4.25 in
Base Width (in)	2.13 in
Bolt Size (in)	1/2 in
Bore Diameter (in)	1.75 in
Foot Height (in)	0.69 in
Base to Center Height (in)	2.13 in
Length Through Bore (in)	1.938 in
Bolt Spacing Max (in)	6.06 in
Bolt Spacing Min (in)	5.44 in
Centerline to Outermost Bearing Face (in)	1.25 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Silver
Options	Corrosion Resistant
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Locking Collar Outside Diameter (in)	2.94 in
Ability to Relubricate	Yes
Setscrew Torque (in-lbs)	240 in/lbs
Inner Race Heat Treat Method	Zone-Hardened
Max Operating Temperature (F)	220 °F
Vibration Frequency Outer Ring Defect	0.0673 cps
End Cap Available	Yes
Vibration Frequency Inner Ring Defect	0.0994 cps
Base Length (in)	7.50 in
Inner Ring Outside Diameter (in)	2.297 in
Static Load Rating (lb)	5,139 lb
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Fundamental Train	0.0067 cps
Bearing Insert Finish	Phosphorus Nickel Coated
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Maximum Speed (RPM)	1600 rpm
Bearing Type	Standard Duty
Size Code	2-111
Cage Type	Land Riding Retainer
Vibration Frequency Roller Spin	0.0417 cps
Shaft Locking Type	Concentric
Housing Material	Stainless Steel
Fixed vs. Expansion	Fixed
Grease Fitting Thread Size	1/4-28
Radial Clearance	Standard
Dynamic Load Rating (lb)	7,901 lb
Misalignment Capability	±2.0° Misalignment - Static Only
Insert	PN-28T

General Specifications

UPC	662461343388
Weight	6.50 LB
Packaged Length	5.19 IN
Packaged Width	2.13 IN
Packaged Height	7.81 IN
HTC	8483.20.8040
Country of Origin	United States of America
