• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	2.13 in
Overall Height (in)	4.25 in
Base Width (in)	2.13 in
Overall Length (in)	7.5 in
Bolt Size (in)	1/2 in
Bore Diameter (in)	1.6875 in
Base to Center Height (in)	2.13 in
Foot Height (in)	0.69 in
Length Through Bore (in)	1.938 in
Bolt Spacing Max (in)	6.06 in
Centerline to Outermost Bearing Face (in)	1.188 in
Bolt Spacing Min (in)	5.44 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Bore Shape	Straight
Housing Construction	One Piece
Misalignment Type	Static Only
Housing Color	Silver
Outer Ring Land Profile	Tapered Lands
Options	Corrosion Resistant - Reduced Maintenance - Lubed for Life
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Setscrew Torque (in-lbs)	125-165 in/lbs
Ability to Relubricate	No
Vibration Frequency Fundamental Train	0.0067 cps
Vibration Frequency Outer Ring Defect	0.0673 cps
Fixed vs. Expansion	Fixed
Cage Type	Land Riding Retainer
Size Code	2-111
Base Length (in)	7.50 in
Insert	PN-27
Bearing Insert Finish	Phosphorus Nickel Coated
Static Load Rating (lb)	5,139 lb
Inner Ring Outside Diameter (in)	2.297 in
Bearing Type	Standard Duty
Bearing Insert Material	52100 Bearing Steel
Radial Clearance	Standard
Shaft Locking Type	Set Screw
Vibration Frequency Roller Spin	0.0417 cps
Max Operating Temperature (F)	220 °F
End Cap Available	Yes
Dynamic Load Rating (lb)	7,901 lb
Vibration Frequency Inner Ring Defect	0.0994 cps
Housing Material	Stainless Steel
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Misalignment Capability	±2.0° Misalignment - Static Only
Grease Fitting Thread Size	1/4-28
Maximum Speed (RPM)	1600 rpm

General Specifications

UPC	662461374641
Weight	6.50 LB
Packaged Length	5.19 IN
Packaged Width	2.13 IN
Packaged Height	7.81 IN
HTC	8483.20.8040
Country of Origin	United States of America
