• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Length (in)	7.25 in
Overall Height (in)	3.94 in
Overall Width (in)	2.13 in
Base Width (in)	2.13 in
Bolt Size (in)	1/2 in
Bore Diameter (in)	1.5 in
Base to Center Height (in)	1.9375 in
Foot Height (in)	0.69 in
Length Through Bore (in)	1.935 in
Bolt Spacing Min (in)	4.88 in
Centerline to Outermost Bearing Face (in)	1.188 in
Bolt Spacing Max (in)	5.88 in
Bolt Spacing (in)	5.38 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Silver
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Options	Corrosion Resistant
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Vibration Frequency Inner Ring Defect	0.0909 cps
Vibration Frequency Roller Spin	0.0376 cps
Size Code	2-19
Radial Clearance	Standard
Vibration Frequency Outer Ring Defect	0.0591 cps
Base Length (in)	7.25 in
Inner Ring Outside Diameter (in)	2.07 in
Insert	PN-24
Maximum Speed (RPM)	1750 rpm
Static Load Rating (lb)	4,467 lb
Bearing Insert Finish	Phosphorus Nickel Coated
Housing Material	Stainless Steel
Vibration Frequency Fundamental Train	0.0066 cps
Shaft Locking Type	Set Screw
End Cap Available	Yes
Grease Fitting Thread Size	1/4-28
Bearing Type	Standard Duty
Cage Type	Land Riding Retainer
Max Operating Temperature (F)	220 °F
Dynamic Load Rating (lb)	7,340 lb
Bearing Insert Material	52100 Bearing Steel
Fixed vs. Expansion	Fixed
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Misalignment Capability	±2.0° Misalignment - Static Only

General Specifications

UPC	662461335741
Weight	6.01 LB
Packaged Length	4.63 IN
Packaged Width	2.31 IN
Packaged Height	7.50 IN
HTC	8483.20.8040
Country of Origin	United States of America
