• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Base Width (in)	2.13 in
Overall Length (in)	7.5 in
Overall Width (in)	2.13 in
Overall Height (in)	4.25 in
Bolt Size (in)	1/2 in
Bore Diameter (mm)	45 mm
Base to Center Height (in)	2.13 in
Foot Height (in)	0.69 in
Length Through Bore (in)	1.938 in
Bolt Spacing Min (in)	5.44 in
Centerline to Outermost Bearing Face (in)	1.188 in
Bolt Spacing Max (in)	6.06 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Housing Construction	One Piece
Bore Shape	Straight
Outer Ring Land Profile	Tapered Lands
Housing Color	Silver
Options	Corrosion Resistant - Reduced Maintenance - Lubed for Life
Misalignment Type	Static Only
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Setscrew Torque (in-lbs)	125-165 in/lbs
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	No
Vibration Frequency Fundamental Train	0.0067 cps
Bearing Insert Material	52100 Bearing Steel
Grease Fitting Thread Size	1/4-28
Max Operating Temperature (F)	220 °F
Vibration Frequency Inner Ring Defect	0.0994 cps
Maximum Speed (RPM)	1600 rpm
Radial Clearance	Standard
Size Code	2-111
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Shaft Locking Type	Set Screw
Dynamic Load Rating (lb)	7,901 lb
Vibration Frequency Outer Ring Defect	0.0673 cps
Cage Type	Land Riding Retainer
Base Length (in)	7.50 in
Fixed vs. Expansion	Fixed
Vibration Frequency Roller Spin	0.0417 cps
End Cap Available	Yes
Bearing Type	Standard Duty
Inner Ring Outside Diameter (in)	2.297 in
Bearing Insert Finish	Phosphorus Nickel Coated
Housing Material	Stainless Steel
Misalignment Capability	±2.0° Misalignment - Static Only
Insert	PN-209
Static Load Rating (lb)	5,139 lb

General Specifications

UPC	662461392041
Weight	7.04 LB
Packaged Length	5.19 IN
Packaged Width	2.13 IN
Packaged Height	7.81 IN
HTC	8483.20.8040
Country of Origin	United States of America
