• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Skwezloc® Concentric locking for near perfect concentricity with fluoropolymer coated collar and corrosion resistant cap screw
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Base Width (in)	1.88 in
Overall Width (in)	1.88 in
Overall Length (in)	8.75 in
Overall Height (in)	3.38 in
Bolt Size (in)	1/2 in
Bore Diameter (in)	1.1875 in
Base to Center Height (in)	1.6875 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.56 in
Bolt Spacing Min (in)	4.44 in
Centerline to Outermost Bearing Face (in)	0.98 in
Bolt Spacing Max (in)	5.06 in
Bolt Spacing (in)	4.75 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Misalignment Type	Static Only
Housing Color	Silver
Options	Corrosion Resistant
Outer Ring Land Profile	Standard
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Locking Collar Outside Diameter (in)	2.19 in
Ability to Relubricate	Yes
Vibration Frequency Fundamental Train	0.0066 cps
Inner Ring Outside Diameter (in)	1.594 in
Vibration Frequency Outer Ring Defect	0.0595 cps
End Cap Available	Yes
Base Length (in)	6.5 in
Bearing Insert Material	52100 Bearing Steel
Bearing Insert Finish	Phosphorus Nickel Coated
Misalignment Capability	±2.0° Misalignment - Static Only
Fixed vs. Expansion	Fixed
Bearing Type	Standard Duty
Shaft Locking Type	Concentric
Vibration Frequency Roller Spin	0.0385 cps
Housing Material	Stainless Steel
Radial Clearance	Standard
Cage Type	Land Riding Retainer
Dynamic Load Rating (lb)	4,381 lb
Vibration Frequency Inner Ring Defect	0.0905 cps
Size Code	2-13
Static Load Rating (lb)	2,567 lb
Max Operating Temperature (F)	220 °F
Maximum Speed (RPM)	2300 rpm
Insert	PN-19T
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Grease Fitting Thread Size	1/4-28

General Specifications

UPC	662461348017
Weight	3.60 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.8040
Country of Origin	United States of America
