• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Height (in)	3.38 in
Base Width (in)	1.88 in
Overall Length (in)	8.75 in
Overall Width (in)	1.88 in
Bolt Size (in)	1/2 in
Bore Diameter (in)	1.1875 in
Base to Center Height (in)	1.6875 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.497 in
Bolt Spacing Min (in)	4.44 in
Centerline to Outermost Bearing Face (in)	0.875 in
Bolt Spacing Max (in)	5.06 in
Bolt Spacing (in)	4.75 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Bore Shape	Straight
Housing Construction	One Piece
Options	Corrosion Resistant - Reduced Maintenance - Lubed for Life
Outer Ring Land Profile	Tapered Lands
Misalignment Type	Static Only
Housing Color	Silver
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Ability to Relubricate	No
Inner Race Heat Treat Method	Zone-Hardened
Base Length (in)	6.5 in
Max Operating Temperature (F)	220 °F
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Bearing Type	Standard Duty
Dynamic Load Rating (lb)	4,381 lb
Vibration Frequency Outer Ring Defect	0.0595 cps
Vibration Frequency Fundamental Train	0.0066 cps
Size Code	2-13
Insert	PN-19
Bearing Insert Finish	Phosphorus Nickel Coated
Housing Material	Stainless Steel
Shaft Locking Type	Set Screw
Bearing Insert Material	52100 Bearing Steel
Fixed vs. Expansion	Fixed
Static Load Rating (lb)	2,567 lb
End Cap Available	Yes
Cage Type	Land Riding Retainer
Vibration Frequency Roller Spin	0.0385 cps
Inner Ring Outside Diameter (in)	1.594 in
Grease Fitting Thread Size	1/4-28
Vibration Frequency Inner Ring Defect	0.0905 cps
Maximum Speed (RPM)	2300 rpm
Radial Clearance	Standard
Misalignment Capability	±2.0° Misalignment - Static Only

General Specifications

UPC	662461352427
Weight	3.60 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.8040
Country of Origin	United States of America
