• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Skwezloc® Concentric locking for near perfect concentricity with fluoropolymer coated collar and corrosion resistant cap screw
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	1.50 in
Base Width (in)	1.50 in
Overall Height (in)	2.81 in
Overall Length (in)	8.75 in
Bolt Size (in)	3/8 in
Bore Diameter (in)	1 in
Foot Height (in)	0.50 in
Base to Center Height (in)	1.4375 in
Length Through Bore (in)	1.375 in
Bolt Spacing Max (in)	4.5 in
Bolt Spacing Min (in)	3.75 in
Centerline to Outermost Bearing Face (in)	0.813 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Bore Shape	Straight
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Options	Corrosion Resistant
Housing Color	Silver
Misalignment Type	Static Only
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Ability to Relubricate	Yes
Locking Collar Outside Diameter (in)	1.94 in
Inner Race Heat Treat Method	Zone-Hardened
Misalignment Capability	±2.0° Misalignment - Static Only
Size Code	2-015
Maximum Speed (RPM)	2700 rpm
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Bearing Type	Standard Duty
Vibration Frequency Outer Ring Defect	0.0682 cps
Vibration Frequency Roller Spin	0.0442 cps
Grease Fitting Thread Size	1/4-28
Bearing Insert Finish	Phosphorus Nickel Coated
Inner Ring Outside Diameter (in)	1.375 in
Base Length (in)	5.50 in
Shaft Locking Type	Concentric
Dynamic Load Rating (lb)	2,801 lb
Radial Clearance	Standard
Max Operating Temperature (F)	220 °F
Vibration Frequency Inner Ring Defect	0.0985 cps
End Cap Available	Yes
Static Load Rating (lb)	1,651 lb
Housing Material	Stainless Steel
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Fundamental Train	0.0068 cps
Fixed vs. Expansion	Fixed
Cage Type	Land Riding Retainer
Insert	PN-16T

General Specifications

UPC	662461339152
Weight	1.57 LB
Packaged Length	3.50 IN
Packaged Width	1.69 IN
Packaged Height	5.75 IN
HTC	8483.20.8040
Country of Origin	United States of America
