• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High strength composite with reinforced stainless steel bolt ferrules for high load capacity and increased strength around the bolt holes.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	1.88 in
Overall Length (in)	5.5 in
Overall Height (in)	3.77 in
Base Width (in)	1.88 in
Bolt Size (in)	1/2 in
Bore Diameter (in)	1.25 in
Base to Center Height (in)	1.875 in
Foot Height (in)	0.66 in
Length Through Bore (in)	1.685 in
Bolt Spacing Min (in)	4.69 in
Centerline to Outermost Bearing Face (in)	1 in
Bolt Spacing Max (in)	5.31 in
Bolt Spacing (in)	5 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Bore Shape	Straight
Housing Construction	One Piece
Options	Corrosion Resistant
Housing Color	Light Gray
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Shaft Locking Type	Set Screw
Max Operating Temperature (F)	220 °F
Vibration Frequency Fundamental Train	0.0066 cps
Size Code	2-17
Bearing Type	Standard Duty
Bearing Insert Finish	Phosphorus Nickel Coated
Vibration Frequency Roller Spin	0.0386 cps
Inner Ring Outside Diameter (in)	1.851 in
Maximum Speed (RPM)	2000 rpm
Fixed vs. Expansion	Fixed
Vibration Frequency Inner Ring Defect	0.0905 cps
Cage Type	Land Riding Retainer
Housing Material	Composite
Dynamic Load Rating (lb)	5,782 lb
Static Load Rating (lb)	3,493 lb
Bearing Insert Material	52100 Bearing Steel
Grease Fitting Thread Size	1/4-28
Base Length (in)	6.56 in
End Cap Available	Yes
Vibration Frequency Outer Ring Defect	0.0595 cps
Misalignment Capability	±2.0° Misalignment - Static Only
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Radial Clearance	Standard
Insert	PN-20

General Specifications

UPC	662461339053
Weight	1.97 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.8040
Country of Origin	United States of America
