• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High strength composite with reinforced stainless steel bolt ferrules for high load capacity and increased strength around the bolt holes.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	1.50 in
Base Width (in)	1.50 in
Overall Length (in)	5.5 in
Overall Height (in)	2.81 in
Bolt Size (in)	3/8 in
Bore Diameter (in)	1 in
Foot Height (in)	0.56 in
Base to Center Height (in)	1.4375 in
Length Through Bore (in)	1.375 in
Bolt Spacing Min (in)	3.75 in
Bolt Spacing Max (in)	4.5 in
Centerline to Outermost Bearing Face (in)	0.813 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Misalignment Type	Static Only
Housing Color	Light Gray
Outer Ring Land Profile	Standard
Options	Corrosion Resistant
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Pillow Block, Two Bolt
Seal Type	Multi-Lip Contact Seal
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Max Operating Temperature (F)	220 °F
Grease Fitting Thread Size	1/4-28
Vibration Frequency Roller Spin	0.0442 cps
End Cap Available	Yes
Maximum Speed (RPM)	2700 rpm
Housing Material	Composite
Shaft Locking Type	Set Screw
Vibration Frequency Fundamental Train	0.0068 cps
Insert	PN-16
Fixed vs. Expansion	Fixed
Vibration Frequency Outer Ring Defect	0.0682 cps
Bearing Insert Finish	Phosphorus Nickel Coated
Static Load Rating (lb)	1,651 lb
Base Length (in)	5.50 in
Cage Type	Land Riding Retainer
Bearing Type	Standard Duty
Vibration Frequency Inner Ring Defect	0.0985 cps
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Dynamic Load Rating (lb)	2,801 lb
Bearing Insert Material	52100 Bearing Steel
Radial Clearance	Standard
Inner Ring Outside Diameter (in)	1.375 in
Size Code	2-015
Misalignment Capability	±2.0° Misalignment - Static Only

General Specifications

UPC	662461335659
Weight	0.92 LB
Packaged Length	3.50 IN
Packaged Width	1.69 IN
Packaged Height	5.75 IN
HTC	8483.20.8040
Country of Origin	United States of America
