• Powder coated epoxy cast iron housing with extended inner bearing inside rubber grommet
• Zone hardened inner ring with 120° spacing setscrew with diamond faceted setscrews
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.

Dimensions

Base Width (in)	1.38 in
Overall Length (in)	5.5 in
Overall Height (in)	2.81 in
Overall Width (in)	1.56 in
Bolt Size (in)	3/8 in
Bore Diameter (in)	1 in
Base to Center Height (in)	1.4375 in
Foot Height (in)	0.50 in
Length Through Bore (in)	1.563 in
Bolt Spacing Min (in)	3.25 in
Centerline to Outermost Bearing Face (in)	0.875 in
Bolt Spacing Max (in)	4.38 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Color	Gray
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Housing Material	Rubber
End Cap Available	No
Bearing Insert Finish	Phosphorus Nickel Coated
Insert	SRC-16
Vibration Frequency Outer Ring Defect	0.0682 cps
Radial Clearance	Standard
Vibration Frequency Inner Ring Defect	0.0985 cps
Misalignment Capability	±2.0° Misalignment - Static Only
Static Load Rating (lb)	1,651 lb
Bearing Type	Standard Duty
Inner Ring Outside Diameter (in)	1.375 in
Shaft Locking Type	Set Screw
Vibration Frequency Roller Spin	0.0442 cps
Vibration Frequency Fundamental Train	0.0068 cps
Max Operating Temperature (F)	220 °F
Bearing Insert Material	52100 Bearing Steel
Fixed vs. Expansion	Fixed
Dynamic Load Rating (lb)	2,801 lb
Lubricant	Lithium Complex NLGI 2 Grease
Size Code	2-015
Maximum Speed (RPM)	6350 rpm
Base Length (in)	5.50 in
Cage Type	Land Riding Retainer
Grease Fitting Thread Size	1/4-28

General Specifications

UPC	662461010044
Weight	2.40 LB
Packaged Length	3.50 IN
Packaged Width	1.69 IN
Packaged Height	5.75 IN
HTC	8483.20.8040
Country of Origin	United States of America
