• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	5.25 in
Bolt Size (in)	5/8 in
Overall Length (in)	8.5 in
Overall Height (in)	2.313 in
Bore Diameter (in)	2.1875 in
Foot Height (in)	0.81 in
Length Through Bore (in)	2.188 in
Bolt Spacing (in)	7.2500 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Silver
Outer Ring Land Profile	Standard
Backside Shield/Seal	Optional backside shield available order separate
Misalignment Type	Static Only
Options	Corrosion Resistant
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Two Bolt
Seal Type	Multi-Lip Contact Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
End Cap Available	Yes
Inner Ring Outside Diameter (in)	2.719 in
Insert	PN-35
Bearing Insert Material	52100 Bearing Steel
Radial Clearance	Standard
Static Load Rating (lb)	6,601 lb
Max Operating Temperature (F)	220 °F
Shaft Locking Type	Set Screw
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Insert Finish	Phosphorus Nickel Coated
Cage Type	Land Riding Retainer
Maximum Speed (RPM)	1350 rpm
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Housing Material	Stainless Steel
Bearing Type	Standard Duty
Max Operating Temperature (C)	104 °C
Grease Fitting Thread Size	1/8 NPT
Size Code	2-23
Dynamic Load Rating (lb)	9,752 lb
Fixed vs. Expansion	Fixed

General Specifications

UPC	662461337059
Weight	8.40 LB
Packaged Length	8.44 IN
Packaged Width	5.50 IN
Packaged Height	2.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
