• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	5.25 in
Bolt Size (in)	5/8 in
Overall Height (in)	2.313 in
Overall Length (in)	8.5 in
Bore Diameter (in)	2 in
Foot Height (in)	0.81 in
Length Through Bore (in)	2.188 in
Bolt Spacing (in)	7.2500 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Housing Color	Silver
Misalignment Type	Static Only
Options	Corrosion Resistant
Outer Ring Land Profile	Standard
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Flange, Two Bolt
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Bearing Type	Standard Duty
Maximum Speed (RPM)	1350 rpm
Dynamic Load Rating (lb)	9,752 lb
Inner Ring Outside Diameter (in)	2.719 in
Max Operating Temperature (F)	220 °F
Insert	PN-32
Grease Fitting Thread Size	1/4-28
Max Operating Temperature (C)	104 °C
Static Load Rating (lb)	6,601 lb
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Cage Type	Land Riding Retainer
Housing Material	Stainless Steel
Shaft Locking Type	Set Screw
End Cap Available	Yes
Size Code	2-23
Bearing Insert Material	52100 Bearing Steel
Misalignment Capability	±2.0° Misalignment - Static Only
Fixed vs. Expansion	Fixed
Radial Clearance	Standard
Bearing Insert Finish	Phosphorus Nickel Coated

General Specifications

UPC	662461337837
Weight	8.40 LB
Packaged Length	8.44 IN
Packaged Width	5.50 IN
Packaged Height	2.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
