• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Skwezloc® Concentric locking for near perfect concentricity with fluoropolymer coated collar and corrosion resistant cap screw
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	4.56 in
Bolt Size (in)	9/16 in
Overall Length (in)	7.44 in
Overall Height (in)	2.157 in
Bore Diameter (mm)	50 mm
Foot Height (in)	0.56 in
Length Through Bore (in)	2.09 in
Bolt Spacing (in)	6.1875 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Outer Ring Land Profile	Tapered Lands
Housing Color	Silver
Misalignment Type	Static Only
Backside Shield/Seal	Optional backside shield available order separate
Options	Corrosion Resistant - Reduced Maintenance - Lubed for Life
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Two Bolt
Seal Type	Multi-Lip Contact Seal
Housing Style	Flange Block
Ability to Relubricate	No
Inner Race Heat Treat Method	Zone-Hardened
Radial Clearance	Standard
Fixed vs. Expansion	Fixed
Maximum Speed (RPM)	1500 rpm
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Insert Finish	Phosphorus Nickel Coated
Shaft Locking Type	Concentric
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Grease Fitting Thread Size	1/8 NPT
Dynamic Load Rating (lb)	7,889 lb
Inner Ring Outside Diameter (in)	2.469 in
Housing Material	Stainless Steel
Max Operating Temperature (C)	104 °C
Cage Type	Land Riding Retainer
Bearing Type	Standard Duty
Insert	PN-210T
Static Load Rating (lb)	5,216 lb
Bearing Insert Material	52100 Bearing Steel
End Cap Available	Yes
Size Code	2-115
Max Operating Temperature (F)	220 °F

General Specifications

UPC	662461370773
Weight	6.70 LB
Packaged Length	4.63 IN
Packaged Width	2.31 IN
Packaged Height	7.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
