• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Skwezloc® Concentric locking for near perfect concentricity with fluoropolymer coated collar and corrosion resistant cap screw
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	2.75 in
Bolt Size (in)	7/16 in
Overall Length (in)	4.88 in
Overall Height (in)	1.498 in
Bore Diameter (in)	1 in
Foot Height (in)	0.53 in
Length Through Bore (in)	1.48 in
Bolt Spacing (in)	3.8891 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Housing Color	Silver
Options	Corrosion Resistant
Backside Shield/Seal	Optional backside shield available order separate
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Two Bolt
Seal Type	Multi-Lip Contact Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Setscrew Torque (in-lbs)	70 in/lbs
Locking Collar Outside Diameter (in)	1.98 in
Vibration Frequency Roller Spin	0.0442 cps
Misalignment Capability	±2.0° Misalignment - Static Only
Shaft Locking Type	Concentric
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
End Cap Available	Yes
Maximum Speed (RPM)	2700 rpm
Bearing Insert Finish	Phosphorus Nickel Coated
Insert	PN-16T
Max Operating Temperature (F)	220 °F
Cage Type	Land Riding Retainer
Size Code	2-015
Vibration Frequency Inner Ring Defect	0.0985 cps
Bearing Type	Standard Duty
Housing Material	Stainless Steel
Fixed vs. Expansion	Fixed
Dynamic Load Rating (lb)	2,801 lb
Vibration Frequency Outer Ring Defect	0.0682 cps
Vibration Frequency Fundamental Train	0.0068 cps
Bearing Insert Material	52100 Bearing Steel
Static Load Rating (lb)	1,651 lb
Inner Ring Outside Diameter (in)	1.375 in
Radial Clearance	Standard
Grease Fitting Thread Size	1/4-28

General Specifications

UPC	662461347928
Weight	1.60 LB
Packaged Length	4.00 IN
Packaged Width	1.50 IN
Packaged Height	3.94 IN
HTC	8483.20.4040
Country of Origin	United States of America
