• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High strength composite with reinforced stainless steel bolt ferrules for high load capacity and increased strength around the bolt holes.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Skwezloc® Concentric locking for near perfect concentricity with fluoropolymer coated collar and corrosion resistant cap screw
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	4.13 in
Bolt Size (in)	1/2 in
Overall Height (in)	2.016 in
Overall Length (in)	6.94 in
Bore Diameter (mm)	40 mm
Foot Height (in)	0.56 in
Bolt Spacing (in)	5.6569 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Housing Color	Light Gray
Misalignment Type	Static Only
Options	Corrosion Resistant
Backside Shield/Seal	Optional backside shield available order separate
Outer Ring Land Profile	Standard
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Two Bolt
Seal Type	Multi-Lip Contact Seal
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Maximum Speed (RPM)	1750 rpm
Size Code	2-19
Dynamic Load Rating (lb)	7,340 lb
Insert	PN-208T
Shaft Locking Type	Concentric
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Bearing Insert Material	52100 Bearing Steel
Cage Type	Land Riding Retainer
Inner Ring Outside Diameter (in)	2.063 in
Fixed vs. Expansion	Fixed
Housing Material	Composite
End Cap Available	Yes
Max Operating Temperature (F)	220 °F
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Type	Standard Duty
Radial Clearance	Standard
Grease Fitting Thread Size	1/4-28
Bearing Insert Finish	Phosphorus Nickel Coated
Static Load Rating (lb)	4,467 lb

General Specifications

UPC	662461368572
Weight	2.50 LB
Packaged Length	4.63 IN
Packaged Width	2.31 IN
Packaged Height	7.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
