• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High strength composite with reinforced stainless steel bolt ferrules for high load capacity and increased strength around the bolt holes.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Bolt Size (in)	7/16 in
Overall Width (in)	3.25 in
Overall Height (in)	1.563 in
Overall Length (in)	5.7 in
Bore Diameter (mm)	30 mm
Overall Height to End Cap (in)	2.45 in
Foot Height (in)	0.53 in
Overall Length (mm)	144.5 mm
Length Through Bore (in)	1.5 in
Bolt Spacing (in)	4.596 in
Bolt Spacing (mm)	116.7 mm

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Misalignment Type	Static Only
Outer Ring Land Profile	Tapered Lands
Backside Shield/Seal	Optional backside shield available order separate
Housing Color	Light Gray
Options	Corrosion Resistant - Reduced Maintenance - Lubed for Life
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Two Bolt
Seal Type	Multi-Lip Contact Seal
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	No
Setscrew Torque (in-lbs)	35-45 in/lbs
Bearing Insert Finish	Phosphorus Nickel Coated
Radial Clearance	Standard
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Vibration Frequency Inner Ring Defect	0.0905 cps
Inner Ring Outside Diameter (in)	1.587 in
Vibration Frequency Fundamental Train	0.0066 cps
Misalignment Capability	±2.0° Misalignment - Static Only
Insert	PN-206
Bearing Type	Standard Duty
Bearing Insert Material	52100 Bearing Steel
Housing Material	Composite
End Cap Available	Yes
Vibration Frequency Outer Ring Defect	0.0595 cps
Shaft Locking Type	Set Screw
Maximum Speed (RPM)	2300 rpm
Static Load Rating (lb)	2,567 lb
Vibration Frequency Roller Spin	0.0385 cps
Size Code	2-13
Fixed vs. Expansion	Fixed
Grease Fitting Thread Size	1/4-28
Max Operating Temperature (F)	220 °F
Cage Type	Land Riding Retainer
Dynamic Load Rating (lb)	4,381 lb

General Specifications

UPC	662461352526
Weight	1.06 LB
Packaged Length	3.50 IN
Packaged Width	1.69 IN
Packaged Height	5.75 IN
HTC	8483.20.4040
Country of Origin	United States of America
