• 440C Stainless steel for corrosion resistance.
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	4.63 in
Bore Diameter (in)	1.4375 in
Foot Height (in)	0.56 in
Overall Height (in)	1.75 in
Length Through Bore (in)	1.6875 in
Overall Length (in)	4.63 in
Bolt Size (in)	0.5 in
Bolt Spacing (in)	3.6250 in
Centerline to Outermost Bearing Face (in)	1 in

Technical Specifications

Housing Construction	One Piece
Backside Shield/Seal	Optional backside shield available order separate
Outer Ring Land Profile	Standard
Bore Shape	Straight
Housing Type	Flange, Four Bolt
Misalignment Type	Static Only
Pilot Configuration	No Pilot
Rolling Element	Ball Bearing
Cage Material	PPS - Polyphenylene Sulfide
Housing Base	Solid
Seal Type	Triple Lip Contact Seal
Housing Color	Silver
Certifications	IP69K
Options	Corrosion Resistant
Inner Race Heat Treat Method	Through Hardened with annealed set screw hole
Ability to Relubricate	Yes
Max Operating Temperature (F)	220 °F
Insert	SS-23
Dynamic Load Rating (lb)	4,915 lb
Misalignment Capability	±2.0° Misalignment - Static Only
Maximum Speed (RPM)	2000 rpm
Bearing Insert Material	440C Stainless Steel
Housing Backside Inner Diameter	3.3125
Grease Fitting Thread Size	1/4 - 28 NF
Inner Ring Outside Diameter (in)	1.859375 in
End Cap Available	Yes
Static Load Rating (lb)	3,493 lb
Fixed vs. Expansion	No
Cage Type	Land Riding Retainer
Housing Material	Stainless Steel
Shaft Locking Type	Set Screw
Radial Clearance	Standard
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Housing Width (in)	4.63 in

General Specifications

UPC	662461421642
Weight	1.50 LB
Packaged Length	4.00 IN
Packaged Width	1.50 IN
Packaged Height	3.94 IN
HTC	8483.20.4040
Country of Origin	United States of America
