• 440C Stainless steel for corrosion resistance.
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• USDA H1 complaint food grade grease

Dimensions

Overall Length (in)	3.38 in
Bore Diameter (in)	0.75 in
Length Through Bore (in)	1.21875 in
Overall Width (in)	3.38 in
Overall Height (in)	1.28125 in
Bolt Size (in)	0.375 in
Foot Height (in)	0.44 in
Centerline to Outermost Bearing Face (in)	0.71875 in
Bolt Spacing (in)	2.5000 in

Technical Specifications

Housing Type	Flange, Four Bolt
Certifications	IP69K
Housing Construction	One Piece
Housing Base	Solid
Bore Shape	Straight
Seal Type	Triple Lip Contact Seal
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Backside Shield/Seal	Optional backside shield available order separate
Rolling Element	Ball Bearing
Housing Color	Silver
Cage Material	PPS - Polyphenylene Sulfide
Pilot Configuration	No Pilot
Options	Corrosion Resistant
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Through Hardened with annealed set screw hole
Cage Type	Land Riding Retainer
Static Load Rating (lb)	1,444 lb
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Housing Backside Inner Diameter	2
Fixed vs. Expansion	No
End Cap Available	Yes
Radial Clearance	Standard
Misalignment Capability	±2.0° Misalignment - Static Only
Inner Ring Outside Diameter (in)	1.1875 in
Dynamic Load Rating (lb)	2,219 lb
Maximum Speed (RPM)	3100 rpm
Housing Material	Stainless Steel
Insert	SS-12
Shaft Locking Type	Set Screw
Grease Fitting Thread Size	1/4 - 28 NF
Max Operating Temperature (F)	220 °F
Bearing Insert Material	440C Stainless Steel
Housing Width (in)	3.38 in

General Specifications

UPC	662461421604
Weight	1.50 LB
Packaged Length	4.00 IN
Packaged Width	1.50 IN
Packaged Height	3.94 IN
HTC	8483.20.4040
Country of Origin	United States of America
