• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Bolt Size (in)	5/8 in
Overall Width (in)	6.88 in
Overall Height (in)	2.688 in
Overall Length (in)	6.88 in
Bore Diameter (in)	2.4375 in
Foot Height (in)	0.81 in
Length Through Bore (in)	2.559 in
Bolt Spacing (in)	5.6250 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Misalignment Type	Static Only
Housing Color	Silver
Backside Shield/Seal	Backside Shield included loose in box
Outer Ring Land Profile	Tapered Lands
Options	Corrosion Resistant - Reduced Maintenance - Lubed for Life
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Flange, Four Bolt
Housing Style	Flange Block
Setscrew Torque (in-lbs)	250-300 in/lbs
Ability to Relubricate	No
Inner Race Heat Treat Method	Zone-Hardened
Radial Clearance	Standard
Lube Fitting Type	HOUSING PLUGGED
Bearing Type	Standard Duty
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Bearing Insert Finish	Phosphorus Nickel Coated
Size Code	2-27
Max Operating Temperature (F)	220 °F
Housing Material	Stainless Steel
Bearing Insert Material	52100 Bearing Steel
End Cap Available	Yes
Fixed vs. Expansion	Fixed
Housing Backside Inner Diameter	5
Inner Ring Outside Diameter (in)	2.981 in
Grease Fitting Thread Size	1/8 NPT
Static Load Rating (lb)	8,150 lb
Maximum Speed (RPM)	1250 rpm
Insert	PN-39
Shaft Locking Type	Set Screw
Misalignment Capability	±2.0° Misalignment - Static Only
Dynamic Load Rating (lb)	11,789 lb
Cage Type	Land Riding Retainer

General Specifications

UPC	662461338803
Weight	12.41 LB
Packaged Length	7.19 IN
Packaged Width	7.00 IN
Packaged Height	3.31 IN
HTC	8483.20.4040
Country of Origin	United States of America
