• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Bolt Size (in)	9/16 in
Overall Width (in)	5.38 in
Overall Height (in)	2.047 in
Overall Length (in)	5.38 in
Bore Diameter (in)	1.6875 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.934 in
Bolt Spacing (in)	4.125 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Options	Corrosion Resistant
Backside Shield/Seal	Optional backside shield available order separate
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Color	Silver
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Flange, Four Bolt
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Misalignment Capability	±2.0° Misalignment - Static Only
Size Code	2-111
Radial Clearance	Standard
Bearing Insert Finish	Phosphorus Nickel Coated
Insert	PN-27
Housing Material	Stainless Steel
Static Load Rating (lb)	5,139 lb
End Cap Available	Yes
Housing Backside Inner Diameter	3.88
Bearing Type	Standard Duty
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Cage Type	Land Riding Retainer
Dynamic Load Rating (lb)	7,901 lb
Bearing Insert Material	52100 Bearing Steel
Fixed vs. Expansion	Fixed
Grease Fitting Thread Size	1/4-28
Shaft Locking Type	Set Screw
Inner Ring Outside Diameter (in)	2.307 in
Max Operating Temperature (F)	220 °F
Maximum Speed (RPM)	1600 rpm

General Specifications

UPC	662461338780
Weight	5.70 LB
Packaged Length	5.50 IN
Packaged Width	5.38 IN
Packaged Height	3.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
