• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Bolt Size (in)	1/2 in
Overall Width (in)	5.13 in
Overall Length (in)	5.13 in
Overall Height (in)	2.016 in
Bore Diameter (in)	1.5 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.938 in
Bolt Spacing (in)	4.0000 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Housing Color	Silver
Misalignment Type	Static Only
Outer Ring Land Profile	Tapered Lands
Backside Shield/Seal	Optional backside shield available order separate
Options	Corrosion Resistant - Reduced Maintenance - Lubed for Life
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Flange, Four Bolt
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	No
Bearing Insert Finish	Phosphorus Nickel Coated
Fixed vs. Expansion	Fixed
End Cap Available	Yes
Bearing Type	Standard Duty
Misalignment Capability	±2.0° Misalignment - Static Only
Static Load Rating (lb)	4,467 lb
Bearing Insert Material	52100 Bearing Steel
Dynamic Load Rating (lb)	7,340 lb
Inner Ring Outside Diameter (in)	2.07 in
Insert	PN-24
Cage Type	Land Riding Retainer
Radial Clearance	Standard
Maximum Speed (RPM)	1750 rpm
Grease Fitting Thread Size	1/4-28
Housing Backside Inner Diameter	3.5
Size Code	2-19
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Max Operating Temperature (F)	220 °F
Housing Material	Stainless Steel
Shaft Locking Type	Set Screw

General Specifications

UPC	662461337479
Weight	5.42 LB
Packaged Length	5.50 IN
Packaged Width	2.13 IN
Packaged Height	5.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
