• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	5.63 in
Bolt Size (in)	9/16 in
Bolt Size (mm)	M16 mm
Overall Length (in)	5.63 in
Overall Height (in)	2.156 in
Bore Diameter (mm)	50 mm
Foot Height (in)	0.56 in
Length Through Bore (in)	2.027 in
Bolt Spacing (in)	4.3750 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Outer Ring Land Profile	Tapered Lands
Misalignment Type	Static Only
Backside Shield/Seal	Backside Shield included loose in box
Options	Corrosion Resistant - Reduced Maintenance - Lubed for Life
Housing Color	Silver
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Four Bolt
Seal Type	Multi-Lip Contact Seal
Housing Style	Flange Block
Ability to Relubricate	No
Inner Race Heat Treat Method	Zone-Hardened
Bearing Type	Standard Duty
Bearing Insert Material	52100 Bearing Steel
Static Load Rating (lb)	5,216 lb
Radial Clearance	Standard
Housing Material	Stainless Steel
Maximum Speed (RPM)	1500 rpm
Fixed vs. Expansion	Fixed
Max Operating Temperature (F)	220 °F
Housing Backside Inner Diameter	4
Inner Ring Outside Diameter (in)	2.469 in
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Insert	PN-210
Size Code	2-115
Grease Fitting Thread Size	1/8 NPT
Misalignment Capability	±2.0° Misalignment - Static Only
Cage Type	Land Riding Retainer
Dynamic Load Rating (lb)	7,889 lb
Bearing Insert Finish	Phosphorus Nickel Coated
End Cap Available	Yes
Shaft Locking Type	Set Screw

General Specifications

UPC	662461352502
Weight	6.70 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
