• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	3.75 in
Bolt Size (in)	7/16 in
Overall Length (in)	3.75 in
Overall Height (in)	1.438 in
Bore Diameter (in)	1 in
Foot Height (in)	0.53 in
Overall Height to End Cap (in)	2.35 in
Length Through Bore (in)	1.375 in
Bolt Spacing (in)	2.7500 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Housing Color	Silver
Options	Corrosion Resistant
Outer Ring Land Profile	Tapered Lands
Misalignment Type	Static Only
Backside Shield/Seal	Optional backside shield available order separate
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Flange, Four Bolt
Housing Style	Flange Block
Setscrew Torque (in-lbs)	45 in/lbs
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Operating Temperature Range (F)	0 to 150 °F
Radial Clearance	Standard
Housing Material	Stainless Steel
Insert	PN-16
Misalignment Capability	±2.0° Misalignment - Static Only
Vibration Frequency Roller Spin	0.0442 cps
Bearing Insert Finish	Phosphorus Nickel Coated
Static Load Rating (lb)	1,651 lb
Grease Fitting Thread Size	1/4-28
Vibration Frequency Outer Ring Defect	0.0682 cps
Cage Type	Land Riding Retainer
Vibration Frequency Fundamental Train	0.0068 cps
Dynamic Load Rating (lb)	2,801 lb
Housing Backside Inner Diameter	2.38
Shaft Locking Type	Set Screw
Max Operating Temperature (F)	220 °F
Vibration Frequency Inner Ring Defect	0.0985 cps
Size Code	2-015
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Maximum Speed (RPM)	2700 rpm
End Cap Available	Yes
Inner Ring Outside Diameter (in)	1.375 in
Bearing Insert Material	52100 Bearing Steel
Fixed vs. Expansion	Fixed
Bearing Type	Standard Duty
Housing Width (in)	3.75 in

General Specifications

UPC	662461335758
Weight	2.21 LB
Packaged Length	4.00 IN
Packaged Width	1.50 IN
Packaged Height	3.94 IN
HTC	8483.20.4040
Country of Origin	United States of America
