• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High strength composite with reinforced stainless steel bolt ferrules for high load capacity and increased strength around the bolt holes.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	4.34 in
Bolt Size (in)	7/16 in
Overall Height (in)	1.563 in
Overall Length (in)	4.34 in
Bore Diameter (mm)	30 mm
Foot Height (in)	0.53 in
Overall Height to End Cap (in)	2.47 in
Length Through Bore (in)	1.5 in
Bolt Spacing (in)	3.2500 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Options	Corrosion Resistant
Outer Ring Land Profile	Tapered Lands
Misalignment Type	Static Only
Housing Color	Light Gray
Backside Shield/Seal	Optional backside shield available order separate
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Four Bolt
Seal Type	Multi-Lip Contact Seal
Housing Style	Flange Block
Operating Temperature Range (F)	0 to 150 °F
Inner Race Heat Treat Method	Zone-Hardened
Setscrew Torque (in-lbs)	45 in/lbs
Ability to Relubricate	Yes
Inner Ring Outside Diameter (in)	1.594 in
Static Load Rating (lb)	2,567 lb
Housing Material	Composite
Size Code	2-13
Vibration Frequency Outer Ring Defect	0.0595 cps
Vibration Frequency Fundamental Train	0.0066 cps
End Cap Available	Yes
Shaft Locking Type	Set Screw
Vibration Frequency Inner Ring Defect	0.0905 cps
Max Operating Temperature (F)	150 °F
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Fixed vs. Expansion	Fixed
Radial Clearance	Standard
Dynamic Load Rating (lb)	4,381 lb
Maximum Speed (RPM)	2300 rpm
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Insert Material	52100 Bearing Steel
Bearing Type	Standard Duty
Vibration Frequency Roller Spin	0.0385 cps
Grease Fitting Thread Size	1/4-28
Insert	PN-206
Bearing Insert Finish	Phosphorus Nickel Coated
Cage Type	Land Riding Retainer
Housing Backside Inner Diameter	2.56

General Specifications

UPC	662461347348
Weight	2.10 LB
Packaged Length	4.50 IN
Packaged Width	1.69 IN
Packaged Height	4.56 IN
HTC	8483.20.4040
Country of Origin	United States of America
