Dimensions

Foot Height (in)	0.5 in
Overall Height (in)	1.88 in
Bolt Size (in)	1/2 in
Overall Length (in)	6.13 in
Length Through Bore (in)	1.685 in
Base to Center Height (in)	4.25 in
Overall Width (in)	3.75 in
Bore Diameter (in)	1.25 in
Overall Height to End Cap (in)	2.78 in
Bolt Spacing (in)	2.0000 in

Technical Specifications

Ability to Relubricate	Yes
Cage Material	PPS - Polyphenylene Sulfide
Certifications	IP69K
Pilot Configuration	No Pilot
Housing Type	Flange, Bracket, Three Bolt
Housing Construction	One Piece
Housing Color	Silver
Outer Ring Land Profile	Standard
Housing Style	Flange Block
Rolling Element	Ball Bearing
Bore Shape	Straight
Misalignment Type	Static Only
Inner Race Heat Treat Method	Through Hardened with annealed set screw hole
Vibration Frequency Inner Ring Defect	0.0905 cps
Fixed vs. Expansion	Fixed
Max Operating Temperature (F)	220 °F
Bearing Insert Material	440C Stainless Steel
Misalignment Capability	±2.0° Misalignment - Static Only
Maximum Speed (RPM)	2300 rpm
Grease Fitting Thread Size	1/4-28
Dynamic Load Rating (lb)	4,915 lb
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Bearing Centerline to Bolt Hole Center (in)	2.375 in
End Cap Available	Yes
Static Load Rating (lb)	3,493 lb
Cage Type	Land Riding Retainer
Radial Clearance	Standard
Vibration Frequency Roller Spin	0.0386 cps
Bolt Spacing Height Direction (in)	1.25 in
Vibration Frequency Fundamental Train	0.0066 cps
Vibration Frequency Outer Ring Defect	0.0595 cps
Size Code	2-17
Bearing Type	Standard Duty
Insert	SS-20
Housing Material	Stainless Steel
Inner Ring Outside Diameter (in)	1.862 in
Shaft Locking Type	Set Screw
Housing Width (in)	3.75 in

General Specifications

UPC	662461422373
Weight	4.50 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.8040
Country of Origin	United States of America
