Dimensions

Length Through Bore (in)	1.685 in
Bore Diameter (in)	1.25 in
Overall Width (in)	3.75 in
Overall Height to End Cap (in)	2.78 in
Base to Center Height (in)	4.25 in
Overall Height (in)	1.88 in
Overall Length (in)	6.13 in
Bolt Size (in)	1/2 in
Foot Height (in)	0.5 in
Bolt Spacing (in)	2.0000 in

Technical Specifications

Inner Race Heat Treat Method	Through Hardened with annealed set screw hole
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Type	Flange, Bracket, Three Bolt
Housing Style	Flange Block
Housing Construction	One Piece
Bore Shape	Straight
Ability to Relubricate	No
Housing Color	Silver
Rolling Element	Ball Bearing
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Pilot Configuration	No Pilot
Misalignment Capability	±2.0° Misalignment - Static Only
Cage Type	Land Riding Retainer
Vibration Frequency Roller Spin	0.0386 cps
End Cap Available	Yes
Fixed vs. Expansion	Fixed
Bearing Insert Material	440C Stainless Steel
Vibration Frequency Fundamental Train	0.0066 cps
Vibration Frequency Inner Ring Defect	0.0905 cps
Maximum Speed (RPM)	2300 rpm
Bolt Spacing Height Direction (in)	1.25 in
Bearing Centerline to Bolt Hole Center (in)	2.375 in
Shaft Locking Type	Set Screw
Dynamic Load Rating (lb)	4,915 lb
Housing Material	Stainless Steel
Grease Fitting Thread Size	1/4-28
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Static Load Rating (lb)	3,493 lb
Max Operating Temperature (F)	220 °F
Radial Clearance	Standard
Inner Ring Outside Diameter (in)	1.862 in
Size Code	2-17
Bearing Type	Standard Duty
Vibration Frequency Outer Ring Defect	0.0595 cps
Housing Width (in)	3.75 in

General Specifications

UPC	662461422496
Weight	4.50 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.8040
Country of Origin	United States of America
