• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	3.75 in
Bolt Size (in)	1/2 in
Overall Length (in)	6.13 in
Overall Height (in)	1.88 in
Bore Diameter (in)	1.4375 in
Overall Height to End Cap (in)	2.78 in
Base to Center Height (in)	4.25 in
Foot Height (in)	0.5 in
Length Through Bore (in)	1.685 in
Bolt Spacing (in)	2.0000 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Color	Silver
Options	Corrosion Resistant
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Flange, Bracket, Three Bolt
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
End Cap Available	Yes
Cage Type	Land Riding Retainer
Misalignment Capability	±2.0° Misalignment - Static Only
Fixed vs. Expansion	Fixed
Max Operating Temperature (F)	220 °F
Inner Ring Outside Diameter (in)	1.862 in
Bearing Centerline to Bolt Hole Center (in)	2.375 in
Bearing Insert Finish	Phosphorus Nickel Coated
Dynamic Load Rating (lb)	5,782 lb
Housing Material	Stainless Steel
Shaft Locking Type	Set Screw
Size Code	2-17
Vibration Frequency Outer Ring Defect	0.0595 cps
Bearing Type	Standard Duty
Bolt Spacing Height Direction (in)	1.25 in
Maximum Speed (RPM)	2000 rpm
Insert	PN-23
Bearing Insert Material	52100 Bearing Steel
Radial Clearance	Standard
Static Load Rating (lb)	3,493 lb
Grease Fitting Thread Size	1/4-28
Vibration Frequency Inner Ring Defect	0.0905 cps
Vibration Frequency Roller Spin	0.0386 cps
Vibration Frequency Fundamental Train	0.0066 cps
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Housing Width (in)	3.75 in

General Specifications

UPC	662461338582
Weight	3.10 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.4040
Country of Origin	United States of America
