Dimensions

Length Through Bore (in)	1.688 in
Bore Diameter (in)	1.25 in
Foot Height (in)	0.56 in
Overall Length (in)	6.13 in
Overall Height (in)	1.75 in
Bolt Size (in)	1/2 in
Overall Width (in)	3.75 in
Bolt Spacing (in)	5.1250 in

Technical Specifications

Housing Style	Flange Block
Housing Type	Flange, Two Bolt
Rolling Element	Ball Bearing
Cage Material	PPS - Polyphenylene Sulfide
Bore Shape	Straight
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Pilot Configuration	No Pilot
Certifications	IP69K
Housing Color	Silver
Housing Construction	One Piece
Ability to Relubricate	Yes
Vibration Frequency Outer Ring Defect	0.0595 cps
Size Code	2-17
Fixed vs. Expansion	Fixed
Vibration Frequency Inner Ring Defect	0.0905 cps
Bearing Type	Standard Duty
Grease Fitting Thread Size	1/4-28
Bearing Insert Material	440C Stainless Steel
Shaft Locking Type	Set Screw
Misalignment Capability	±2.0° Misalignment - Static Only
Dynamic Load Rating (lb)	4,915 lb
Vibration Frequency Roller Spin	0.0386 cps
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Max Operating Temperature (F)	220 °F
Inner Ring Outside Diameter (in)	1.859 in
End Cap Available	Yes
Static Load Rating (lb)	3,493 lb
Cage Type	Land Riding Retainer
Maximum Speed (RPM)	2000 rpm
Vibration Frequency Fundamental Train	0.0066 cps
Housing Material	Stainless Steel
Radial Clearance	Standard

General Specifications

UPC	662461422434
Weight	1.50 LB
Packaged Length	3.13 IN
Packaged Width	1.75 IN
Packaged Height	3.13 IN
HTC	8482.10.5052
Country of Origin	China
