• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	3.75 in
Bolt Size (in)	1/2 in
Overall Length (in)	6.13 in
Overall Height (in)	1.75 in
Bore Diameter (in)	1.25 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.688 in
Bolt Spacing (in)	5.1250 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Options	Corrosion Resistant
Housing Color	Silver
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Backside Shield/Seal	Backside Shield included loose in box
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Two Bolt
Seal Type	Multi-Lip Contact Seal
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Setscrew Torque (in-lbs)	75-100 in/lbs
Maximum Speed (RPM)	2000 rpm
End Cap Available	Yes
Vibration Frequency Outer Ring Defect	0.0595 cps
Static Load Rating (lb)	3,493 lb
Fixed vs. Expansion	Fixed
Dynamic Load Rating (lb)	5,782 lb
Housing Material	Stainless Steel
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Insert Finish	Phosphorus Nickel Coated
Size Code	2-17
Inner Ring Outside Diameter (in)	1.859 in
Vibration Frequency Fundamental Train	0.0066 cps
Insert	PN-20
Grease Fitting Thread Size	1/4-28
Shaft Locking Type	Set Screw
Vibration Frequency Roller Spin	0.0386 cps
Cage Type	Land Riding Retainer
Bearing Insert Material	52100 Bearing Steel
Max Operating Temperature (F)	220 °F
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Radial Clearance	Standard
Vibration Frequency Inner Ring Defect	0.0905 cps
Bearing Type	Standard Duty

General Specifications

UPC	662461341438
Weight	3.52 LB
Packaged Length	5.00 IN
Packaged Width	2.00 IN
Packaged Height	5.00 IN
HTC	8483.20.4040
Country of Origin	United States of America
