• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
• Solid construction with machined base was designed for minimal gaps and no fillers
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	4.25 in
Bolt Size (in)	7/16 in
Overall Length (in)	4.25 in
Overall Height (in)	1.563 in
Bore Diameter (in)	1.25 in
Overall Height to End Cap (in)	1.93 in
Foot Height (in)	0.53 in
Length Through Bore (in)	1.5 in
Bolt Spacing (in)	3.2500 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Housing Color	Silver
Options	Corrosion Resistant
Misalignment Type	Static Only
Outer Ring Land Profile	Tapered Lands
Backside Shield/Seal	Backside Shield included loose in box
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Flange, Four Bolt
Housing Style	Flange Block
Operating Temperature Range (F)	-20 to 220 °F
Setscrew Torque (in-lbs)	45 in/lbs
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Vibration Frequency Inner Ring Defect	0.0905 cps
Vibration Frequency Fundamental Train	0.0066 cps
End Cap Available	Yes
Misalignment Capability	±2.0° Misalignment - Static Only
Max Operating Temperature (F)	220 °F
Fixed vs. Expansion	Fixed
Vibration Frequency Roller Spin	0.0385 cps
Bearing Insert Finish	Phosphorus Nickel Coated
Shaft Locking Type	Set Screw
Bearing Type	Standard Duty
Housing Backside Inner Diameter	2.88
Static Load Rating (lb)	2,567 lb
Grease Fitting Thread Size	1/4-28
Vibration Frequency Outer Ring Defect	0.0595 cps
Size Code	2-13
Cage Type	Land Riding Retainer
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Bearing Insert Material	52100 Bearing Steel
Maximum Speed (RPM)	2300 rpm
Radial Clearance	Standard
Dynamic Load Rating (lb)	4,381 lb
Insert	PN-20R
Housing Material	Stainless Steel
Inner Ring Outside Diameter (in)	1.594 in

General Specifications

UPC	662461341292
Weight	3.25 LB
Packaged Length	4.50 IN
Packaged Width	1.69 IN
Packaged Height	4.56 IN
HTC	8483.20.4040
Country of Origin	United States of America
