• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Left-Hand Threads

Dimensions

Ball Diameter (in)	0.625 in
Thread Size	#5/16-24
Thread Length (in)	1.219 in
Ball Width (in)	0.437 in
Housing Width (in)	0.344 in
Ball Flat Diameter (in)	0.447 in
Head Diameter (in)	0.875 in
Length to Center of Ball (in)	1.88 in

Technical Specifications

Outer Material	Carbon Steel - Corrosion Resistant Plating
Bearing Type	Rod End
Axial Load	300
Misalignment Angle - a Deg. +/-	7
Zerk Fitting SW	Y
Housing Style	Male Rod End
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Product Type	CFM
Series	Commercial
Lubrication Type	Grease
Configuration	Male
Product Selection Available SW	Y
Construction	Two-Piece Rod End with Zerk Fitting
Thread Type	UNF
Lubrication	Zerk Fitting
Type	Male Rod End
Thread	LH
Max Static Radial Load	3,000
Bore Size (in)	0.3125 in
Class	Commercial
Lubrication Method	Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	Yes

General Specifications

UPC	662288725558
Weight	0.08 LB
Packaged Length	2.31 IN
Packaged Width	0.88 IN
Packaged Height	0.44 IN
HTC	8483.30.8055
Country of Origin	Mexico
