• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Left-Hand Threads
• PTFE Liner

Dimensions

Thread Size	#3/4-16
Thread Length (in)	1.719 in
Ball Flat Diameter (in)	0.978 in
Ball Diameter (in)	1.312 in
Head Diameter (in)	1.75 in
Housing Width (in)	0.687 in
Ball Width (in)	0.875 in
Length to Center of Ball (in)	2.88 in

Technical Specifications

Liner	TEFLON* Fabric Liner
Bearing Type	Rod End
Housing Style	Male Rod End
Axial Load	830
Product Type	CFM-T
Product Selection Available SW	Y
Misalignment Angle - a Deg. +/-	7
Race Material	TEFLON
Zerk Fitting SW	N
Configuration	Male
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Thread Type	UNF
Outer Material	Carbon Steel - Corrosion Resistant Plating
Construction	Two-Piece Rod End
Lubrication Type	Self Lubricating
Series	Precision
Thread	LH
Type	Male Rod End
Max Static Radial Load	8,300
Lubrication	No Zerk Fitting
Class	Precision
Bore Size (in)	0.7500 in
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	250 °F

General Specifications

UPC	662288721321
Weight	0.98 LB
Packaged Length	3.75 IN
Packaged Width	1.75 IN
Packaged Height	0.88 IN
HTC	8483.30.8055
Country of Origin	Mexico
