• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads
• Y Stud

Dimensions

Thread Size	#3/8-24
Housing Width (in)	0.406 in
Ball Diameter (in)	0.718 in
Ball Width (in)	0.5 in
Thread Length (in)	1.219 in
Head Diameter (in)	1 in
Ball Flat Diameter (in)	0.517 in
Stud Length to Hex (in)	0.91 in
Length to Center of Ball (in)	1.94 in
Stud Thread Length (in)	0.8125 in
Stud Length to Center of Ball (in)	1.54 in

Technical Specifications

Configuration	Male
Construction	Two-Piece Rod End with Y Stud
Lubrication Type	Grease
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Thread Type	UNF
Product Selection Available SW	N
Y Stud Material	Carbon Steel - corrosion resistant plating
Housing Style	Male Rod End
Series	Commercial
Outer Material	Carbon Steel - Corrosion Resistant Plating
Bearing Type	Rod End
Zerk Fitting SW	N
Product Type	CFM
Axial Load	500
Thread	RH
Max Static Radial Load	5,000
Misalignment Angle B3	22.6
Lubrication	No Zerk Fitting
Type	Male Rod End
Bore Size (in)	0.3750 in
Class	Commercial
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288725008
Weight	0.17 LB
Packaged Length	2.44 IN
Packaged Width	1.00 IN
Packaged Height	1.79 IN
HTC	8483.30.8055
Country of Origin	Mexico
