• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads
• PTFE Liner

Dimensions

Ball Width (in)	0.437 in
Ball Flat Diameter (in)	0.447 in
Housing Width (in)	0.344 in
Thread Length (in)	1.219 in
Ball Diameter (in)	0.625 in
Head Diameter (in)	0.875 in
Thread Size	#5/16-24
Length to Center of Ball (in)	1.88 in

Technical Specifications

Thread Type	UNF
Construction	Two-Piece Rod End
Series	Precision
Product Selection Available SW	Y
Liner	TEFLON* Fabric Liner
Configuration	Male
Bearing Type	Rod End
Lubrication Type	Self Lubricating
Housing Style	Male Rod End
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Zerk Fitting SW	N
Product Type	CFM-T
Race Material	TEFLON
Outer Material	Carbon Steel - Corrosion Resistant Plating
Axial Load	208
Misalignment Angle - a Deg. +/-	7
Type	Male Rod End
Lubrication	No Zerk Fitting
Max Static Radial Load	2,080
Thread	RH
Bore Size (in)	0.3125 in
Class	Precision
Lubrication Method	Self Lubricating
Maximum Ambient Temperature (F)	250 °F
Ability to Relubricate	None

General Specifications

UPC	662288721093
Weight	0.07 LB
Packaged Length	2.31 IN
Packaged Width	0.88 IN
Packaged Height	0.44 IN
HTC	8483.30.8055
Country of Origin	Mexico
