• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads

Dimensions

Housing Width (in)	0.344 in
Thread Size	#5/16-24
Head Diameter (in)	0.875 in
Ball Width (in)	0.437 in
Ball Diameter (in)	0.625 in
Thread Length (in)	1.219 in
Ball Flat Diameter (in)	0.447 in
Length to Center of Ball (in)	1.88 in

Technical Specifications

Housing Style	Male Rod End
Axial Load	300
Lubrication Type	Grease
Product Selection Available SW	Y
Outer Material	Carbon Steel - Corrosion Resistant Plating
Thread Type	UNF
Product Type	CFM
Construction	Two-Piece Rod End with Zerk Fitting
Configuration	Male
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Series	Commercial
Bearing Type	Rod End
Misalignment Angle - a Deg. +/-	7
Zerk Fitting SW	Y
Thread	RH
Max Static Radial Load	3,000
Lubrication	Zerk Fitting
Type	Male Rod End
Bore Size (in)	0.3125 in
Class	Precision
Lubrication Method	Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	Yes

General Specifications

UPC	662288724957
Weight	0.08 LB
Packaged Length	2.31 IN
Packaged Width	0.88 IN
Packaged Height	0.44 IN
HTC	8483.30.8055
Country of Origin	Mexico
