• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads

Dimensions

Head Diameter (in)	2.75 in
Ball Width (in)	1.375 in
Thread Size	#1 1/4-12
Thread Length (in)	2.094 in
Housing Width (in)	1 in
Ball Flat Diameter (in)	1.269 in
Ball Diameter (in)	1.875 in
Length to Center of Ball (in)	4.13 in

Technical Specifications

Lubrication Type	Grease
Axial Load	2,100
Thread Type	UNF
Race Material	TEFLON
Outer Material	Carbon Steel - Corrosion Resistant Plating
Series	Commercial
Zerk Fitting SW	Y
Product Type	CFM
Bearing Type	Rod End
Product Selection Available SW	Y
Misalignment Angle - a Deg. +/-	8.5
Construction	Two-Piece Rod End with Zerk Fitting
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Configuration	Male
Housing Style	Male Rod End
Max Static Radial Load	21,000
Lubrication	Zerk Fitting
Thread	RH
Type	Male Rod End
Class	Commercial
Bore Size (in)	1 in
Lubrication Method	Fitting
Ability to Relubricate	Yes
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288729259
Weight	2.24 LB
Packaged Length	5.50 IN
Packaged Width	2.75 IN
Packaged Height	1.38 IN
HTC	8483.30.8055
Country of Origin	Mexico
