• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Left-Hand Threads

Dimensions

Thread Size	#1/2-20
Thread Length (in)	1.031 in
Housing Width (in)	0.5 in
Base Diameter (in)	0.875 in
Ball Flat Diameter (in)	0.698 in
Ball Diameter (in)	0.937 in
Head Diameter (in)	1.312 in
Ball Width (in)	0.625 in
Length to Center of Ball (in)	2.13 in

Technical Specifications

Housing Style	Female Rod End
Outer Material	Carbon Steel - Corrosion Resistant Plating
Bearing Type	Rod End
Product Type	CFF
Construction	Two-Piece Rod End with Zerk Fitting
Thread Type	UNF
Configuration	Female
Race Material	TEFLON
Lubrication Type	Grease
Series	Commercial
Product Selection Available SW	Y
Zerk Fitting SW	Y
Axial Load	900
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Across Wrench Flats	0.75
Misalignment Angle - a Deg. +/-	6
Thread	LH
Type	Female Rod End
Max Static Radial Load	9,000
Lubrication	Zerk Fitting
Class	Commercial
Bore Size (in)	0.5000 in
Lubrication Method	Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	Yes

General Specifications

UPC	662288725374
Weight	0.29 LB
Packaged Length	2.78 IN
Packaged Width	1.31 IN
Packaged Height	0.75 IN
HTC	8483.30.8055
Country of Origin	Mexico
