• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Left-Hand Threads
• PTFE Liner

Dimensions

Base Diameter (in)	1.125 in
Housing Width (in)	0.687 in
Ball Diameter (in)	1.312 in
Thread Size	#3/4-16
Thread Length (in)	1.531 in
Ball Flat Diameter (in)	0.978 in
Ball Width (in)	0.875 in
Head Diameter (in)	1.75 in
Length to Center of Ball (in)	2.88 in

Technical Specifications

Race Material	TEFLON
Bearing Type	Rod End
Lubrication Type	Self Lubricating
Misalignment Angle - a Deg. +/-	7
Axial Load	830
Product Type	CFF
Outer Material	Carbon Steel - Corrosion Resistant Plating
Thread Type	UNF
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Housing Style	Female Rod End
Configuration	Female
Across Wrench Flats	1
Liner	TEFLON* Fabric Liner
Construction	Two-Piece Rod End
Product Selection Available SW	Y
Series	Precision
Zerk Fitting SW	N
Lubrication	No Zerk Fitting
Max Static Radial Load	8,300
Thread	LH
Type	Female Rod End
Class	Precision
Bore Size (in)	0.7500 in
Lubrication Method	Self Lubricating
Ability to Relubricate	None
Maximum Ambient Temperature (F)	250 °F

General Specifications

UPC	662288721239
Weight	0.59 LB
Packaged Length	3.75 IN
Packaged Width	1.75 IN
Packaged Height	1.00 IN
HTC	8483.30.8055
Country of Origin	Mexico
