• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Left-Hand Threads

Dimensions

Thread Length (in)	1.531 in
Ball Diameter (in)	1.312 in
Thread Size	#3/4-16
Base Diameter (in)	1.125 in
Ball Flat Diameter (in)	0.978 in
Housing Width (in)	0.687 in
Head Diameter (in)	1.75 in
Ball Width (in)	0.875 in
Length to Center of Ball (in)	2.88 in

Technical Specifications

Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Construction	Two-Piece Rod End with Zerk Fitting
Product Type	CFF
Thread Type	UNF
Housing Style	Female Rod End
Across Wrench Flats	1
Lubrication Type	Grease
Axial Load	1,400
Bearing Type	Rod End
Product Selection Available SW	Y
Configuration	Female
Series	Commercial
Misalignment Angle - a Deg. +/-	7
Outer Material	Carbon Steel - Corrosion Resistant Plating
Zerk Fitting SW	Y
Type	Female Rod End
Thread	LH
Lubrication	Zerk Fitting
Max Static Radial Load	14,000
Class	Commercial
Bore Size (in)	0.7500 in
Lubrication Method	Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	Yes

General Specifications

UPC	662288725459
Weight	0.63 LB
Packaged Length	3.75 IN
Packaged Width	1.75 IN
Packaged Height	1.00 IN
HTC	8483.30.8055
Country of Origin	Mexico
